model：ims系列
brand：上海净信
specifications ：ims系列
introduction：上海净信科技系列雪花制冰机的整体设计出之专家之手，让整个操作过程轻松自如，完善的人性化设计呈现科技之美。
vacuum freeze dryers are widely used in medical, pharmaceutical, biological research, chemical and food fields. freeze-dried items are easy to store for a long time, and can be restored to the state before freeze-drying after processing and maintain the original biochemical properties.
this freeze dryer is compact in structure, has the flexibility of a large freeze dryer, takes up less space, and can flexibly process diverse samples. it is extremely cost-effective, suitable for small laboratories, and can choose ordinary type and gland type. multi-manifold general type, gland multi-manifold type, t-frame and many other configurations.
features:
features superior to similar freeze dryers:
1. 7-inch color lcd screen display.
2. liquid crystal display drying curve.
3. the cold trap has a pre-freezing function, saving the cost of a low-temperature refrigerator.
4. danfoss compressor has low noise, high power and long life.
5. mixed environment-friendly refrigerant, green environment-friendly refrigeration capacity is large.
6. the internal heat exchanger effectively reduces the temperature of the cold trap and has a strong water catching capacity
7. anti-oil return vacuum pump to prevent contamination of materials.
8. transparent bell-type drying room, safe and intuitive.
9. optional power distribution defrost function.
10. optional nitrogen gas filling valve.
11. green and environmentally friendly refrigerants that meet the standards
12. display freeze-drying curve in different colors (single curve can be displayed separately)
technical parameter:
参数/型号parameter/model | 10 (台式压盖/普通)10 (desktop gland/normal) | 12(立式压盖/普通)12 (vertical gland/normal) | 18（立式压盖/普通）18 (vertical gland/normal) | 18s （立式带加热功能压盖/普通）18s (vertical gland with heating function/normal) |
空载冷阱温度 no-load cold trap temperature | <-56°c,可选 optional<-80°c | <-56°c,可选optional<-80°c | <-56°c,可选optional<-80°c | <-56°c,可选optional<-80°c |
空载冻干面积(m²）no-load freeze-drying area (m²) | 0.08/0.12 | 0.08/0.12 | 0.12/0.18 | 0.12/0.18 |
盘装物料（l）packing materials (l) | 0.8/1.2 | 0.8/1.2 | 1.9/1.8 | 1.9/1.8 |
捕水能力water catching capacity | 3-4kg/24h | 3-4kg/24h | 6kg/24h | 6kg/24h |
真空度vacuum | <10pa | <10pa | <10pa | <10pa |
整机尺寸（mm） overall size (mm) | 500*395*370 420 | 500 *400*650 420 | 830* 532*900 420 | 830*532*900 420 |
物料托盘规格material pallet specifications | φ200mm 4层(普通型) φ200mm 3层(压盖)φ200mm 4 layers (normal type) φ200mm 3 layers (gland) | φ200mm 4层(普通型) φ200mm 3层(压盖型) φ200mm 4 layers (normal type) φ200mm 3 layers (gland type) | φ240mm 4层 层间距70mm(普通) φ240mm 6层 层间距50mm(普通) 可选φ200mm 3层(压盖) φ240mm 4 layers, layer spacing 70mm (ordinary) φ240mm 6 layers, layer spacing 50mm (ordinary) optional φ200mm 3 layers (gap) | φ240mm 4层 层间距70mm(普通) φ240mm 6层 层间距50mm(普通) 可选φ200mm 3层(压盖)φ240mm 4 layers, layer spacing 70mm (ordinary) φ240mm 6 layers, layer spacing 50mm (ordinary) optional φ200mm 3 layers (gap) |
整机功耗 whole machine power consumption | 1000va | 1000va | 1300va | 1300va |
电源power supply | 220v 50hz /110v 60hz | 220v 50hz /110v 60hz | 220v 50hz /110v 60hz | 220v 50hz /110v 60hz |
西林瓶vialφ12mm | 560/920 | 560/920 | 990/1320 | 990/1320 |
西林瓶vialφ16mm | 285/480 | 285/480 | 555/740 | 555/740 |
西林瓶vialφ22mm | 165/260 | 165/260 | 270/360 | 270/360 |
